MSRP: $47,889.00
Standard bucket capacity,m³ (yd³) 0.35(0.46)
Rated load,kg (lbs) 600 (882)
Operating weight,kg (lbs) 2,200(4,850) Rated power,kW (hp) 17.4 (23.7）| Technical Parameter | |
|
Standard bucket capacity,m³ (yd³)
|
0.35(0.46) |
| Rated load,kg (lbs) | 600 (882) |
| Operating weight,kg (lbs) | 2,200(4,850) |
| Engine | Kubota D1703 |
| Rated power,kW (hp) | 17.4 (23.7） |
| Rated engine speed,rpm | 2200 |
| Engine displacement,ml (in³ï¼‰ | 1,674 (102) |
| Transmission type | HST |
| Speed at Fl/Rl,km/h (mph) | 0~10 (0-6.2} |
| Speed at F2/R2,km/h (mph) | 0~20 (0-12.4) |
| Tire size | 10-16.5 |
| A Wheelbase,mm (ft in) | 1,470(4'9.9") |
| Fuel tank,L (gal) | 35 (9.2) |
| B Ground clearance,mm (ft in) | 220 (8. 7") |
| C Reach at Max height,mm (ft in) | 365（l'2.4") |
| Overall shipping size (L • W • H)，mm (ft in) | 4,010(13'2")*1,338(4'7")*2,282(7'5.8") |
| D Dumping angle,° | 40 |
| E Height at bucket pin,mm (ft in) | 2,728 (8'11.4") |
| F Dumping height,mm (ft in) | 2,010(6'7.1") |
| G Bucket rollback at ground level,° | 48 |
| I Wheel tread,mm (ft in) | 946(3'1.2") |
| J Articulation angle,° | 43 |
| K Turning radius at over bucket,mm (ft in) | 3,280(10'9.1") |
| M Turning radius at inside of tires,mm (ft in) | 1,300(4'2") |
Get Out-The-Door Price
